Product Details
Brand Name: Wuling
Model Number: bingbao
Payment & Shipping Terms
Minimum Order Quantity: 1
| Dimension parameter | Vehicle size: 4870×1610×2430mm |
| Container size: 2770×1470×1510mm, cargo volume: 6.14m³ | |
| Quality parameter | Rated load: 965kg |
| Quality: 1595kg | |
| Total weight: 2690kg | |
| Dynamic system | Battery brand and capacity: Lishen Power 41.6kWh lithium iron phosphate battery |
| Motor: Huichuan United power and Tongyu Xinyuan power permanent magnet synchronous motor | |
| Motor rated power: 30kW | |
| Motor peak power: 60kW | |
| Maximum speed: 80km/h | |
| Endurance: 275km | |
| Chassis configuration | Drive type: middle rear-drive |
| Front suspension type: McPherson | |
| Rear suspension type: 6 leaf springs | |
| Top configuration | Refrigeration unit: can choose Yzhou YZ360E model, support external power supply refrigeration, insulation box to ensure stable temperature of the cargo box |
Exterior and interior
Appearance: Continuation of Wuling card mecha wind design, angular, highly recognizable.
Interior: The main practical, using knob shift, with fabric material seats, the center console a lot of black plastic, durable.
Size and volume
Vehicle size: 4870×1610×2430mm.
Container size: 2770×1470×1510mm, the volume of the cargo box is 6.14m³, which can meet the needs of urban end distribution of small quantities of frozen products.
Quality parameter
Rated load: 965kg.
Quality: 1595kg.
Total weight: 2690kg.
Dynamic system
Battery: Equipped with Lishen Power 41.6kWh lithium iron phosphate battery, to provide stable power support for the vehicle to ensure endurance.
Motor: Equipped with permanent magnet synchronous motor powered by Huichuan United Power and Tongyu Xinyuan power, the rated power of the motor is 30kW, the peak power is 60kW, the maximum speed is 80km/h, the working life is 275km, and the power output is stable, which can meet the daily transportation needs.
Chassis configuration
Drive form: middle rear-drive, this drive form can provide better power performance and control stability, adapt to different road conditions.
Front suspension type: McPherson suspension, simple structure, small space, can provide better comfort and handling.
Rear suspension type: 6 leaf springs, strong load capacity, can ensure the stability and comfort of the vehicle at full load.
Top configuration
Refrigeration unit: can choose the YZ360E model of Yizhou cold machine, support external power supply refrigeration, does not occupy the vehicle power battery, effectively improve the vehicle mileage, while the use of thermal insulation box, can ensure the temperature stability of the cargo box, to provide a good storage environment for refrigerated goods.
Cargo material: The material is made of composite materials, such as glass steel plate + PU insulation board, etc., which has good thermal insulation performance and strength, and can effectively maintain the temperature in the cargo box to ensure the quality of refrigerated goods.
